Electrochemistry Competitive Price Handheld 1.000PPM Ozone O3 Gas Analyser Measuring Instrument
Yuante portable multi gas detector adopt advanced gas sensor and micro control technical, has quick response, high accuracy, great stability and repeatability, it's easy to operate, performance is in the leading level of gas detection industry.
SKY3000 portable multi-gas detector with built-in pump is a new intelligent gas detector, which adopts an advanced integrated circuit, with standard intelligent level design technology, and proprietary digital analog hybrid communication technology.
The detector is of excellent sensitivity and repeatability, which makes it very easy to use and maintain. The detector is made of high-strength engineering plastics, compound non-slip rubber, which is of high strength and good hand feeling. what’s more, the detector is water-proof, dust-proof and explosion-proof.
It is widely used in petroleum, chemical, environmental, metallurgy, refining, gas transmission and distribution, biochemical medicine, agricultural and other industries.portable multi-gas detector with built-in pump is a new intelligent gas detector, which adopts an advanced integrated circuit, with standard intelligent level design technology, and proprietary digital analog hybrid communication technology.
Product specifications
| Gas type | Toxic Gas |
| Measure range | O3, Ozone |
| Resolution | 0.001ppm |
| Response time | ≤30 seconds |
| Precsiion | ≤±2%F.S |
| Automatically test and calibrate after power-on | Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value |
| Unit | PPM and mg/m³ can be switched |
| Data record | Can store 100,000 sets data, the storage interval is adjustable from 5 to 3600 seconds, data can be exported |
| Alarm | 95dB buzzer (@30cm), vibration alarm and flashing red LED and alarm status indication on the screen, alarm latched; diagnostic alarm and battery undervoltage alarm, pump block alarm; man down alarm, with early warning and optional real-time remote Bluetooth notification function |
| Battery | 3.7V rechargeable lithium battery, battery capacity 2200mA |
| Working hours | More than 15 hours in continuous pumping mode |
| Charger | Travel charger with DC interface, charging time ≥ 4 hours |
| Explosion-proof grade | IECEX/ATEX(II IG Ex ia IIC T4
CNEX:Ex ia IIC T4 Ga |
Certification
(EU regulations) | 2004/108/EC(EMC)
1995/5/EC(Radio)
94/9/EC(ATEX) |
| Protection grade | IP67 |
| Working temperature | -20ºC~+50ºC |
| Humidity | 0~90%RH(no condensation) |
| Environmental pressure | 86~106Kpa |
The measuring instrument detector alarm monitors gas leak density by natural diffusion and adopts imported electro-chemical sensor, PID sensor, featuring good sensibility and excellent repeat ability.
The device has embedded micro control technique and simple signal display and English instruction menu, making the operation easy.Complete function and dependability makes the whole device a leader in the nation.
The cover of the detector is refined from high-intensive engineering material (compound elastic rubber), which made the detector touches well, waterproof and explosion-protection
FAQ
Q1: Does the Gas Detector come with the case which includes the charger, calibration gas, and attachment?
A1: It come with the case which includes the charger, instruction and qualification certificate.
Q2: What is the moq?
A2: Usually it is 1 piece.
Q3: Does this Gas Detector come with a clip to attach to my FR shirt?
A4: The detector has installed on its back a belt clip.
Q4: How long is the warranty time of the products?
A5: The warranty period is 1 years from the factory, we also provide lifetime maintenance.
